A plantain banana flour grinding machine is a machine that smashes dried bananas or plantains. The fineness of the banana powder ground by the grinder can be adjusted. This machine has a compact design and reasonable structure, which allows continuous production, low noise, and adjustable feeding speed. This plantain grinding machine mainly impacts force, accompanied by tearing and grinding. It is widely used.
Structure Of Plantain Flour Milling Machine Is Introduced
The components of this machine mainly include: hopper, stainless steel crushing cavity, static tooth plate, heat dissipation belt cover, double sealing ring, door locking screw, screen frame, control switch, discharge port, adjustable anti-vibration feet
Features Of Plantain Banana Flour Grinding Machine
- The discharge port pulverizer is made of 304 high-quality stainless steel, which conforms to the hygienic standards of food production.
- A variety of screen meshes are available, the screen mesh can adjust the grinding thickness, and different grinding fineness can be obtained by replacing the screen mesh.
- Lock the screw compartment cover and tighten the loose nut, and the safety compartment cover device effectively fastens the compartment door to prevent powder leakage.
- Simple and convenient installation and maintenance, compact structure, low power consumption, high efficiency, stable transmission, low working noise, reliable sealing, and good cooling system.
- It can be customized according to the customer’s processing capacity.
Working Video Of Banana Plantain Flour Milling Machine
Working Principle Of Banana Plantain Grinding Machine
The dried banana chips or plantain chips enter the crushing chamber from the feeding hopper through the shaking device. The centrifugal force generated by the high-speed rotation of the movable toothed plate is thrown to the chamber wall from the central part, and the steel tooth is received between the movable toothed plate and the fixed toothed plate. The impact, shearing, grinding, and impact between the materials are crushed, and finally, the materials reach the annular space on the outer wall of the turntable, the fine particles are discharged from the bottom through the shape sieve plate, and the coarse powder is repeatedly crushed in the machine.
Operation Points Of Plantain Banana Flour Grinding Machine
- Before running, check whether the assembly of each part of the plantain flour milling machine is complete and accurate, and check whether the feeding hopper and the main machine are normal. Check if the circuit is normal.
- After the pre-operation preparation and the pre-operation inspection of the plantain grinding machine are confirmed to be correct, prepare to start the operation.
- Run at no-load for about 2 minutes, and observe whether the main engine and the vacuum fan are running smoothly.
- The material can be fed only after the no-load operation is stable.
- The material is quantitatively fed into the crushing chamber at the set speed.
- Maintain proper feed rate.
Technical Data Of Plantain Grinding Machine
|Revolution of spindle||4500r/min||3800r/min||3400r/min||2800r/min|
|Grinding size||10-200 mesh|
